GEPRC SPEEDX2 1104 7500KV Motor (4pcs)

Overview

The GEPRC SPEEDX2 1104 7500KV is a lightweight, high-performance brushless motor developed for 1.6 to 2.2-inch FPV drones. Designed for fast throttle response and precise control, it delivers the power needed for agile freestyle flying, racing, and high-speed micro quad applications.

Optimized for 2S and 3S LiPo batteries, the 7500KV winding provides rapid acceleration while maintaining excellent efficiency. The multi-strand copper windings reduce electrical losses and improve power delivery, while the large hollow motor structure enhances cooling for improved thermal performance during demanding flights.

Built around a 9N12P stator, high-grade N52H magnets, and premium NSK/NMB bearings, the motor offers smooth operation, low vibration, and excellent durability even at extremely high RPM. The precision CNC-machined aircraft-grade aluminium bell keeps the overall weight to just 5.2g, providing an ideal balance between strength and lightweight performance.

Features

• High-performance 7500KV motor optimized for 2S and 3S LiPo batteries.

• Fast throttle response with excellent control for freestyle and racing.

• Multi-strand copper winding reduces resistance and improves efficiency.

• Hollow bell design promotes better heat dissipation during demanding flights.

• Premium NSK/NMB bearings ensure smooth, low-vibration operation.

• High-strength CNC-machined aircraft-grade aluminium housing.

• Lightweight construction at approximately 5.2g including wires.

• Designed for 1.6" to 2.2" micro FPV drones.

Specifications

• Model: GEPRC SPEEDX2 1104 7500KV

• KV Rating: 7500KV

• Maximum Power: 155W

• Peak Current: 13.2A (3S)

• Internal Resistance: 150mΩ

• Magnet Type: N52H

• Bearing Type: NSK/NMB

• Stator Configuration: 9N12P

• Motor Dimensions: Ø14.5 × 11.5mm

• Shaft Diameter: 1.5mm

• Shaft Length: 4.95mm

• Mounting Pattern: 4 × Ø9mm

• Wire Length: 60mm (28AWG)

• Recommended ESC: 20A

• Input Voltage: 7.4V–11.1V (2–3S LiPo)

• Winding: Multi-strand copper

• Weight: 5.2 ± 0.2g (including wires)

Recommended Applications

Suitable for:

• 1.6-inch FPV drones

• 2-inch freestyle drones

• 2.2-inch racing drones

• Lightweight micro quadcopters

Package Includes

• 1 × GEPRC SPEEDX2 1104 7500KV Brushless Motor

• 6 × M2 × 4mm Round Head Screws
